产品简介：
海事卫星终端SatLink FB250
SATLINK FB250是可靠的船载卫星通讯设备，可同时进行语音和数据通讯，设计应用于商船、渔船和游艇。先进的BDU设计包括一个易于使用的扩展槽，允许用户灵活使用，并至大限度地用于以后的增值解决方案。
SATLINK FB250具有鼎盛技术和丰富的功能，包括速率高达284 kbps的标准IP，128 kbps的streaming IP，短信，3.1k语音和传真。紧凑轻质的天线，安装简便快捷。即使在极端恶劣的天气条件下，也能稳定工作。
技术参数：
•频率：发送 1626.5 MHz ～ 1660.5 MHz ，接收 1525.0 MHz ～ 1559.0 MHz ；
•通讯业务：
语音：4 kbps , 3.1 kHz ；
标准IP：284/284 kbps ；
streaming IP：32, 64, 128 kbps ；
传真：G3类 ；
短信：高达 160个字符 ；
•BDU：
尺寸/重量: 314.7 x 295 x 59.4 mm , 3.1 kg ；
扩展槽尺寸：93 x 76 x 17 mm ；
存储温度：-40℃ ～ +80℃ ；
操作温度：-25℃ ～ +55℃ ；
•手柄电话：
尺寸/重量：140 x 55 x 20 mm ，80 g ；
•天线：
尺寸/重量：直径 319.5 mm ，高 277 mm ，3.8 kg ；
存储温度：-40℃ ～ +80℃ ；
操作温度：-25℃ ～ +55℃ ；
线缆：50米 ，RG214 ；
•电源：12VDC -10% ～ 24VDC +30% ；
•接口：2个RJ11、4个RJ45、1个扩展槽、电源LED指示灯 ；
•路由：
LAN / Ethernet：4x10 Base-T Ethernet接口，包括 2 PoE ；
LAN / Standard：IEEE 802.3 10 Base-T Ethernet ；
LAN / 网络协议：TCP/IP、NAT、PAT、HTTP、DHCP Server、MAC ；
•船体运动：
摇摆：+30º/8 ；
颠簸：+10º/6s ；
首摇：+8º/50s ；
突然的向上运动：0.2g ；
摇摆：0.2g ；
起伏：0.5g ；
旋转角速度：±6°/s ；
前进：30节 。
